IMAO ID clamp MBID02 1 piece

Catalog number: MBID02 Features: ● Workpieces can be clamped from the inside. By self-cutting the clamping part, it can accommodate a wide range of workpiece diameters. Applications: ● For workpieces with multiple pieces. Specifications: ● Height (mm): 10.7 ● Clamping force (N): 1100 ● Thread dimensions: M2 x 0.40 ● Clamping diameter (mm): 7.4 ● Suitable workpiece diameter (mm): 4.1 to 7.4 ● Overall diameter (mm): 20.0 ● Allowable expansion diameter (mm): 0.13 ● Recommended expansion diameter when self-cutting (mm): 0.05 Material/Finish: ● Body: Steel (SUM24L) ● Tapered bolt: Steel (SCM440) Set contents/Accessories: ● 1 hexagonal nut ● 1 locking ring (MBID16C/MBID16D only)
