IMAO ID clamp MBID04 1 piece

Catalog number: MBID04 Features: ● Workpieces can be clamped from the inside. By self-cutting the clamping part, it can accommodate a wide range of workpiece diameters. Applications: ● For workpieces with multiple pieces. Specifications: ● Height (mm): 21.8 ● Clamping force (N): 4200 ● Thread dimensions: M4 x 0.70 ● Clamping diameter (mm): 12.4 ● Suitable workpiece diameter (mm): 7.1 to 12.4 ● Overall diameter (mm): 29.72 ● Allowable expansion diameter (mm): 0.13 ● Recommended expansion diameter when self-cutting (mm): 0.07 Material/Finish: ● Body: Steel (SUM24L) ● Tapered bolt: Steel (SCM440) Set contents/Accessories: ● 1 hexagonal nut ● 1 locking ring (MBID16C/MBID16D only)
