IMAO ID clamp MBID06 1 piece

Catalog number: MBID06 Features: ● Workpieces can be clamped from the inside. By self-cutting the clamping part, it can accommodate a wide range of workpiece diameters. Applications: ● For workpieces with multiple pieces. Specifications: ● Height (mm): 24.9 ● Clamping force (N): 8400 ● Thread dimensions: M6 x 1.00 ● Clamping diameter (mm): 14.2 ● Suitable workpiece diameter (mm): 12.2 to 14.2 ● Overall diameter (mm): 31.5 ● Allowable expansion diameter (mm): 0.23 ● Recommended expansion diameter when self-cutting (mm): 0.08 Material/Finish: ● Body: Steel (SUM24L) ● Tapered bolt: Steel (SCM440) Set contents/Accessories: ● 1 hexagonal nut ● 1 locking ring (MBID16C/MBID16D only)
