Catalog number: NSD4MP Features: ●Ebi nuts are blind fasteners that combine the functions of a nut and a rivet. ●Easily attaches to thin materials and pipes that are difficult to tap, and plastic plates that cannot be welded, from one side. ●By using the dedicated Ebi brand nut nut, you can adjust the stroke appropriately according to the thickness of the crimped plate, resulting in a uniform finish. ●Stable nut strength is ensured and it can be firmly installed. ●Comes in a durable plastic case for easy storage. ●Small packs allow you to purchase only the number you need when you need it. Applications: ●For attaching parts to steel and plastic parts of cars (bumpers, etc.). ●For attaching parts to aluminum building materials such as exteriors. ●For attaching accessories to thin plates, connecting pipes and flat plates, leveling agricultural tools and implements, etc. Specifications: ● Crimping plate thickness (mm): 1.0-2.0 ● Pilot hole diameter (mm): 6.1 ● Compatible screw: M4 x 0.7 ● Nut outer diameter (mm): 6 ● Total length (mm): 11.5 ● Flange thickness (mm): 0.8 ● Pack quantity (pcs): 35 ● Head shape: Large flange ● Flange diameter (mm): 9.0 ● Torque strength (N・m): 5.9 ● Thread shear strength (kN): 7.3 ● Eco pack included ● Flat head Material/Finish: ● Steel (SWCH) Caution: ● If used with soft materials or thin base materials, the strength listed in the catalog may not be achieved. ● Please observe the dimensions specified by our company for the appropriate crimping plate thickness and pilot hole diameter, and take into consideration the safety factor when installing. ● Please be sure to read the instruction manual for the tool (nutter) carefully before working. ● Dimensions and weight are nominal values, so there may be some fluctuation in the values.
