EBI High Strength Blind Rivet S Bolt (Round Head) Φ4.8 / Plate Thickness 6.9mm (100 pieces) SNS48069EB 1 box

Catalog number: SNS48069EB Features: ●Strong pulling force (fastening force), excellent earthquake resistance and airtightness. ●Wide range (wide range of fastening plate thickness), so there is no need to prepare many sizes of rivets. ●Multiple base materials can be fastened from one side with one action. ●Compared to welding, it has the advantage of reducing labor and improving productivity. Applications: ●For fastening vehicle bodies such as trucks, distribution boards for logistics equipment such as containers and racks, can manufacturing, etc. Specifications: ● Crimping plate thickness (mm): 1.7-6.9 ● Rivet length (mm): 11.0 ● Flange diameter (mm): 9.8 ● Rivet diameter (mm): 4.8 ● Pilot hole diameter (mm): 4.9-5.0 ● Shear strength (N): 6100 ● Tensile strength (N): 4800 ● Eco box included ● Quantity (pieces): 100 Material/Finish: ● Flange: Steel (carbon steel) ● Shaft: Steel (carbon steel) Caution: ● Please use with careful consideration of working conditions. ● Please read the instruction manual of the tool (riveter) you will be using before working. ● Please observe our specified dimensions for the appropriate crimping plate thickness and pilot hole diameter, and take sufficient safety factors into consideration when installing.
