EBI High Strength Blind Rivet S Bolt (Countersunk Head) Φ6.4 / Plate Thickness 12.0mm (100 Pieces) SNS6412KEB 1 Box

Catalog number: SNS6412KEB Features: ●Strong pulling force (fastening force), excellent earthquake resistance and airtightness. ●Wide range (wide range of fastening plate thickness), so there is no need to prepare many sizes of rivets. ●Multiple base materials can be fastened from one side with one action. ●Compared to welding, it has the advantage of reducing labor and improving productivity. Applications: ●For fastening vehicle bodies such as trucks, distribution boards for logistics equipment such as containers and racks, can manufacturing, etc. Specifications: ● Crimping plate thickness (mm): 3.2-12.0 ● Rivet length (mm): 16.8 ● Flange diameter (mm): 10.0 ● Rivet diameter (mm): 6.4 ● Pilot hole diameter (mm): 6.6-7.0 ● Shear strength (N): 11300 ● Tensile strength (N): 9800 ● Eco box included ● Quantity (pieces): 100 Material/Finish: ● Flange: Steel (carbon steel) ● Shaft: Steel (carbon steel) Caution: ● Please use with careful consideration of working conditions. ● Please read the instruction manual of the tool (riveter) you will be using before working. ● Please observe our specified dimensions for the appropriate crimping plate thickness and pilot hole diameter, and take sufficient safety factors into consideration when installing.
