Sanko IT Hanger ITL-MS Type Stainless Steel ITL-10135MS 25 Pieces

Catalog number: ITL-10135MS Features: * Penetrating construction provides stable holding power. * Tightening penetrating construction does not damage ALC panels. * Spring effect makes installation easy. * Can be installed on walls and floors. Applications: * For ALC panels. ●For hollow walls●For installing distribution boards, gutters, signs, etc. Specifications: ●Screw designation: M10 ●Screw length (mm): 90 ●Counterbore diameter (mm): 17.0 ●Plate length (mm): 55 ●Fastening plate thickness (mm): 1-10 ●Required hollow section (mm): 57 ●Maximum thickness of object to be attached (mm): 10 ●Maximum tensile load (kN): 5.7 ●Length (mm): 135 ●Threaded type ●Boxed Material/Finish: ●Main body: Stainless steel (SUS304 type, SUSXM7) ●Plate section: Stainless steel (SUS304 type) Set contents/Accessories: ●Seat nut Note: ●The maximum tensile load is the value when the ALC panel has a compressive strength of Fc4N/m［［Ｍ２］］.
