Sandvik Spiral Tap CoroTap (780) Nominal size M12 Pitch 1.25mm Thread length 13mm Total length 80mm EX1CPJ2-M12X1.25 1 piece

Catalog number: EX1CPJ2-M12X1.25 Features: ●Highly productive tapping tool. ●High stability due to long tool life and excellent chip control. ●Highly heat-resistant TiN coating ensures long life even in workpieces that tend to trap heat. ●Taps are available for each workpiece material, making selection easy. Applications: ●For blind hole machining. ●Workpiece material: Steel. Specifications: ●Accuracy: 6H ●Nominal size: M12 ●Pitch (mm): 1.25 ●Thread length (mm): 13 ●Total length (mm): 80 ●Shank diameter (mm): 8.5 ●Shank square section (mm): 6.5 ●Pilot hole diameter (mm): 10.75 ●Number of teeth: 2.5 teeth ●Machining thread: Metric thread ●Surface treatment: TiN coating ●Number of teeth (pieces): 4 ●Blade length (mm): 13 ●Blade diameter (mm): 12 Material/Finish: ●High-speed steel (HSS-E)
