Shinwa Laser Level Laser Robo Green Neo ESensor21 Receiver and Tripod Set 71612 1 S

Catalog number: 71612 Features: ● Laser irradiation is vertical lines, horizontal lines, and ground marking points. ● The sensor + motor system allows you to quickly determine lines even in work sites with a lot of vibration and shaking. ● Equipped with a line fixing mode, it is useful when you want to emit a line at an angle. Comes with an AC adapter, allowing for long periods of continuous use. ● Comes standard with a horizontal adjustment tripod adapter. Applications: ● Laser robot used to set various marking standards Specifications: ● Height (mm): 190 ● Width (mm): 128 ● Precision: ±1mm/7.5m ● Automatic correction range: ±3° ● Power supply: 4 alkaline AA batteries or AC adapter ● Protection rating: IP54 When using dry batteries ● Light source: Visible semiconductor laser ● Braking method: Sensor + motor method ● Maximum reach (m): Approximately 35 (when using laser receiver) ● Continuous use time (all line irradiation): Approximately 22 hours ● Battery low warning: When the switch is turned on, the laser light flashes for approximately 8 seconds ● Tilt warning: When the main unit is tilted significantly, the laser light flashes ● Standards: Dustproof and waterproof structure (IP54) ● Compensation: 1 year theft and fire compensation included ● Power supply (V): 4 alkaline AA dry batteries or AC adapter ● Wavelength (nm): 635 (lower spot 650 nm) ● Vertical 1 direction, horizontal 1 direction, ground mark ● Indication accuracy (mm): Vertical line Horizontal line: ±1 at 7.5 m ● Output: 1mw or less (JIS class 2) ● Horizontal line emission angle: Approximately 115 ° ● Vertical line emission angle: Approximately 120 ° ● Line light width (mm): Approximately 1.5 at 5 m Material / Finish: ● Main body: Brass, aluminum die-cast ● Case: ABS resin Set contents/Accessories: ● Laser level: 71602 ● Receiver: 71501 ● Tripod: 76629 ● 4 AA alkaline batteries ● AC adapter ● Level adjustment tripod adapter ● Aluminum case Caution: ● Do not subject the product to shocks such as dropping it. ● Do not look directly into the laser beam or point it at people.
