シンワ測定(株)
Shinwa Laser Level Laser Robo Red Neo E Sensor51AR Receiver and Tripod Set 71516 1 S
Shinwa Laser Level Laser Robo Red Neo E Sensor51AR Receiver and Tripod Set 71516 1 S
Regular price
¥100,007
Regular price
Sale price
¥100,007
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Catalog number: 71516 Features: ● Electronic sensor + motor system that quickly stabilizes the line even in work sites with large vibrations and shaking. ● Line fixed mode is convenient when you want to project a line at an angle. ● Full-circle projection is also possible to the side. ● Comes with an AC adapter that allows long periods of continuous use. Applications: ● For use in setting vertical and horizontal references. Specifications: ● Height (mm): 190 ● Width (mm): 128 ● Precision: ±1mm/7.5m (vertical) ● Automatic correction range: ±3° ● Protection rating: IP54 ● Output: 1mW or less (JIS Class 2) ● Power supply (V): 4 AA alkaline batteries (included), AC adapter (included) ● Vertical 4-direction square, horizontal all-around, ground mark ● Maximum reach: Approximately 35m (when using receiver) ● Vertical line (mm): ±1 at 7.5m ● Horizontal line (mm): ±1.5 at 7.5m ● Center line (mm): ±1 at 7.5m ● Line light width (mm): Approximately 1.5 at 5m Material/Finish: ● Body: ABS resin ● Receiver: ABS resin ● Tripod: Aluminum Set contents/accessories: ● Laser level: 71506 ● Receiver: 71500 ● Tripod: 76629 ● 4 AA alkaline batteries ● Laser glasses ● Aluminum case ● Level adjustment tripod adapter ● AC adapter
