Chiyoda Silencer SUS CSS-FS Type (Breather Vent) R1/8 CSS-01FS 1 pc

Catalog number: CSS-01FS Features: ●Ideal for filtering gases, liquids, medicinal fluids, chemical solutions, etc. The corrosion-resistant stainless steel screen filter is safe even in harsh environments. Applications: ●Used in food processes, chemical equipment, medical equipment, etc. Specifications: ●Volume reduction (dB): 20 or more ●Effective cross-sectional area (mm2): 17 ●Connection diameter: R1/8 ●Total length (mm): 16.0 ●Operating pressure (MPa): 1 ●Operating fluid: air, water, chemicals ●Processed air flow rate (m3/min): 1.0 ●Operating pressure: 1MPa ●Fluid temperature: 5 to 150°C ●Maximum temperature range: 1.6 to 150°C ●Guaranteed pressure resistance: 2MPa Materials/Finish: ●Body: Brass (nickel-plated) ●Element: Stainless steel (SUS304) wire screen
