Self-up screws and an openable cover improve wiring workability
A wide lineup from 3 to 300A
Optional low leakage current type and DIN rail mounting type are available. Rated current AC/DC (A): 20
DC resistance (mΩ): 10max
Rated voltage (AC/DC): 250V
Size: 87 x 52 x 35 mm
Withstand voltage: AC2500V 60s (between line and earth)
Insulation resistance: 100MΩmin (DC.500V/1min
Leakage current: 1.0mA max (250V/60Hz)
Operating temperature range: -25 to +85°C
Derating start temperature: 55℃
