Hataya Airmac C 6.5 x 10mm 10m (gray) ACU-102G 1 unit

Catalogue number: ACU-102G Features: *Hose can be replaced without disassembly. *10m economy model. *Includes adapter to convert mounting brackets made by other companies. *10m economy model that allows hose replacement by pulling out the hose to its full length. *Ratchet type stopper that stops reliably at a fixed length. *Primary side connection is rotary type, so air supply direction can be freely adjusted. *Includes string for pulling out the hose to prevent damage to equipment or bending. Applications: *For automobile maintenance. *For air work. *For production plants. Specifications: ● Hose inner diameter x outer diameter (mm): 6.5 x 10 ● Total hose length (m): 10 ● Primary installation side: with 3/8 plug coupler ● Secondary installation side: with one-touch coupler ● Primary hose length (m): 1.5 ● Operating pressure (MPa): 1.5 ● Width (mm): 302 ● Depth (mm): 116 ● Height (mm): 381 ● Outer diameter (mm): 10 ● Inner diameter (mm): 6.5 ● Color: Gray ● Hose material: Polyurethane ● Total length (m): 10 ● Normal pressure: 1.5MPa (15kgf/cm2) ● Material: Braided thread reinforced 1B braided polyurethane ● Hose specifications: Length 10m x inner diameter 6.5mm x outer diameter 10mm Material/Finish: ● Body: Resin ● Hose: Polyurethane Set contents/Accessories: ● With mounting bracket conversion adapter ● Plug coupler
