Hammer Special Rubber Wheel J Series Swivel SP Included 100mm 413J-XRZ100 1 pc

Catalog number: 413J-XRZ100 Features: ●A caster that uses special rubber wheels that are difficult for cutting chips to get stuck in. The special rubber wheels also have excellent oil resistance, so they can be used in environments where they come into contact with cutting oil. ●The moderate rubber elasticity that hard wheels do not have allows for smooth running. ●The wheel bearing section contains radial ball bearings. Applications: ●An all-purpose caster for medium to heavy loads. Specifications: ● Wheel diameter D (mm): 100 ● Type: Swivel (with stopper) ● Allowable load (daN): 140 ● Allowable load (kgf): 143 ● Wheel width (mm): 32 ● Mounting height H (mm): 140 ● Mounting seat A (mm): 100 ● Mounting seat B (mm): 100 ● Mounting pitch X (mm): 70-80 ● Mounting pitch Y (mm): 70-80 ● Mounting hole diameter P (mm): 11 ● Plate type ● Radial ball bearing included ● Swivel (with stopper) Material/Finish: ● Metal fittings: Steel ● Metal fittings surface treatment: Trivalent chromium conversion treatment ● Wheels: Steel wheels, special rubber Caution: ● Some types of oil may not be usable for long periods of time. Also, the effect may vary depending on the usage environment.
