Fischer Bolt Anchor FAZ2 16/25 C4 (10 pieces) 501432 1 box

Catalogue number: 501432 Features: * Fischer's original expansion sleeve structure allows for maximum load-bearing capacity. * Shallow embedment allows for shallow drill hole depths, reducing interference with reinforcing bars and enabling quicker construction. * International certification demonstrates maximum safety and best performance. Applications: * For concrete and dense stone. * Installation of various mounting frames. * Facility construction. * Handrail exterior construction, etc. Specifications: ●Screw designation: M16 ●Screw length (mm): 84 ●Total length (mm): 148 ●Maximum thickness of object to be attached (mm): 25 ●Drill diameter (mm): 16 ●Standard installation torque (N・m): 110 ●Maximum tensile load (kN): 18.8 ●Maximum shear load (kN): 40.5 ●Effective embedment depth (mm): 85 ●Embedded depth (mm): 135 ●Pre-drilled hole diameter (mm): 16 ●European technical approval (ETA-05/0069) ●Boxed Material/Finish: ●Highly corrosion-resistant stainless steel (equivalent to SUS836L)
