Catalog number: SU-SL-PM6X1 Features: ● Extends tool life in medium-speed machining. ● Finishes good flank surface. ● Improves tap runout accuracy. ● Reverse twist spiral is used for stainless steel through hole machining, improving chip removal and extending tool life. ● Can be used at cutting speeds of 10 to 20 m/min. However, fully synchronous feed is recommended for speeds of 15 m/min or more, and is ideal for through hole machining. Applications: ● For through hole machining. ● Workpiece materials: stainless steel, low, medium and high carbon steel, alloy steel. Specifications: ● Precision: P2 ● Precision notation: P grade ● Nominal dimension: M6 ● Pitch (mm): 1 ● Thread length (mm): 15 ● Overall length (mm): 62 ● Shank diameter (mm): 6 ● Square shank section (mm): 4.5 ● Countersink diameter (mm): 5.09 ● Number of engaging threads: 5 ● Machined thread: Metric thread ● Surface treatment: Oxidation treatment ● Tap grade: P grade ● Excellent effect on machining stainless steel (SUS304) Material/Finish: ● High-speed tool steel (HSS) Caution: ● Do not use this tap on machines that are not equipped with a fully synchronous lead feed mechanism, as it will cause the female thread to expand or break.
