YUEI Screw-in type Swivel Stainless steel caster Rubber Wheel diameter 100mm With stopper E type SUS-ET-S type Screw size M16 x 40 Pitch 2 SUS-ET-100RHS-M16-40 1 piece

Catalogue number: SUS-ET-100RHS-M16-40 Features: ●Uses all-stainless steel fittings with excellent water and corrosion resistance. ●Uses rubber wheels with excellent running performance. Applications: ●All-stainless steel food carts, medicine carts, wagons, etc. Specifications: ●Wheel diameter D (mm): 100 ●Type: With swivel S ●Allowable load (daN): 50 ●Allowable load (kgf): 51 ●Wheel width (mm): 25 ●Mounting height H (mm): 126 ●Axle length L (mm): 40 ●Thread T: M16 ●Thread pitch (mm): 2 ●Allowable load (N): 500 ●Swivel type (with stopper) ●Screw-in type Materials/Finish: ●Fittings: Stainless steel ●Wheels: Rubber
