Micro flow meter 10~150mL/min NTFZ-4S-150 1 piece

The measurement method is a TOF type using a thermal marker, and unique digital processing has been used to achieve high-precision measurements. By using the optional communication adapter, various functions such as power supply to the main unit and flow rate monitor can be supported. The integrated display structure allows visual confirmation of the flow rate on-site, making it suitable for experiments and research purposes. Flow rate range: 10 to 150 mL/min Connection shape/tube: outer diameter φ4mm hard tube Fluids used: Pure water, chemicals (fluids that do not corrode the liquid-contacting parts, fluids that do not adhere to and solidify on the liquid-contacting parts) Operating pressure range: 0 to 500kPa Pressure resistance: 700kPa Fluid Measurement Accuracy 10-30mL/min±1%FS 30-150mL/min±5%RD Fluid temperature/ambient temperature range: 15 to 50°C Wetted parts material: PTFE, quartz glass Output specifications: Flow rate (current) / 4 to 20 mA, Flow rate (frequency pulse) / NPN open connector Power supply voltage: DC24V±10% Power consumption: MAX 50mA
