Catalogue number: BN-27T5-15 Features: ●Removes moisture and debris from the air to supply clean air. ●The liquid level is displayed by a color-changing sight glass. Specifications: ●Filtration accuracy (μm): 5 ●Operating pressure (MPa): 0.05-1 ●Processed air flow rate (［［M3］］/min): 2.5 ●Connection diameter: Rc1/2 ●Total length (mm): 170 ●Operating fluid: Air ●Fluid temperature (℃): 5-60 ●Fluid temperature: 5-60℃ ●Drain discharge method: Manual (however, it will automatically discharge if the pressure falls below 0.05MPa) ●Operating pressure: 0.05-1.0MPa
