Nippon Seiki Drain Trap for Medium Pressure NH-503J2H 1 pc

Catalogue number: NH-503J2H Features: ● A magnet is built into the float, and the magnetic force ensures that the drain is automatically discharged. ● The float system eliminates the waste of air. ● Automatically discharges accumulated drain. Applications: ● Automatically discharges accumulated drain. Specifications: ● Operating pressure (MPa): 0.15 to 1.40 ● Drain discharge amount (cm3/time): 10 ● Connection diameter: Rc1/2 ● Width (mm): 100 ● Depth (mm): 100 ● Height (mm): 148 ● Fluid used: Air ● Fluid temperature (℃): 5 to 60 ● Fluid temperature: 5 to 60℃ ● Drain discharge method: Float type auto drain
