Nippon Seiki FRL unit 8A integrated type BN-2510-8 1 unit

Catalog number: BN-2510-8 Features: ● A compact unit that integrates three components of FRL. ● Removes moisture and debris from the air, maintains constant pressure, and supplies lubricating oil. Applications: ● Removes moisture and debris from the air, maintains constant pressure, and supplies lubricating oil. Specifications: ● Filtration accuracy (μm): 40 ● Operating pressure (MPa): 1 ● Processed air flow rate (m3/min): 0.65 ● Connection diameter: Rc1/4 ● Oil storage capacity (cm3): 30 ● Overall length (mm): 171 ● Overall width (mm): 130 ● Set pressure (MPa): 0.05-0.85 ● Fluid used: Air ● Fluid temperature (℃): 5-60 ● Fluid temperature: 5-60℃ ● Drain discharge method: Manual (However, 25T0 will automatically discharge when the pressure falls below 0.05MPa) ● Oil used: Type 1 turbine oil (equivalent to ISO VG#32) Note: ● Pressure gauge (model: BN-PG40A-10K) is sold separately.
