Catalog number: BN-25T0-8 Features: ● A compact unit that integrates three points of FRL. ● Removes moisture and debris from the air, maintains pressure and supplies lubricating oil. Applications: ● Removes moisture and debris from the air, maintains pressure and supplies lubricating oil. Specifications: ● Filtration accuracy (μm): 5 ● Operating pressure (MPa): 1 ● Processing air flow rate (［［M3］］/min): 0.70 ● Connection port size: Rc1/4 ● Oil storage capacity (［［CM3］］): 50 ● Overall length (mm): 203 ● Overall width (mm): 75 ● Set pressure (MPa): 0.05 to 0.85 ● Fluid used: Air ● Fluid temperature (℃): 5 to 60 ● Fluid temperature: 5 to 60℃ ● Drain discharge method: Manual (However, 25T0 will automatically discharge when the pressure falls below 0.05MPa) ● Oil used: Turbine oil type 1 (equivalent to ISO VG#32)
