Nitto High Coupler Ace Plastic 20PMPLA 20PM-PLA 1 piece

Catalog number: 20PM-PLA Features: ● Has the same pressure resistance as metal products. ● Lightweight, only 1/4 the weight of metal products, making it easy to handle. ● Suitable for a wide range of fluids, including not only air but also water. Specifications: ● Pressure resistance (MPa): 1.5 ● Counterpart mounting size: Rc1/4 ● Hexagonal face size (mm): 17 ● Operating temperature range (℃): -20℃ to +60℃ ● Maximum operating pressure (MPa): 1.0 ● Fluid used: air, water ● Operating pressure: 1.0 ● Operating temperature range: -20 to 60℃ ● Maximum operating pressure: 1.0MPa ● Compatible socket: Nitto Kohki High Coupler Series Material/Finish: ● Body: Engineering plastic (PBT, POM)
