NOF Technology Thermoproof G-2 G-2 1 CS

Catalog number: G-2 Features: ●This is a product with a label made from thermo paint. ●It is an irreversible temperature indicator that will not return to its original color once it has changed color. Applications: ●Temperature control in heat treatment processes. Temperature measurement in laboratory equipment. Specifications: ● Primary color: White/Blue/White/Purple ● Color after discoloration: Brownish gray/Brownish white/Greenish gray/White ● Discoloration temperature (℃): 360-410-440-450 ● Element size (mm): 10×6 ● Sticker size (mm): 10×37 ● Element size (φmm): ±10℃ ● Sheet size (mm): 10×37 ● Temperature range (℃): 360℃ to 450℃ ● Temperature pitch (℃): 360℃, 410℃, 440℃, 450℃ ● Measurement accuracy: ±10℃ ● 4-point display type ● For indoor use only ● With adhesive Material/Finish: ● Thermochromic pigment ● Silicone resin base material ● Adhesive ● Release film Note: ● Discoloration temperature varies slightly depending on the heating speed, heating time, pressure, reactive gas, etc. ● At low temperatures below 10℃, the flexibility of the label decreases and the label may crack. ● At temperatures below 15℃, the adhesive strength may decrease and the label may not be able to be attached. In such a case, adjust the temperature of the label and the area where it is attached to about 25°C. ●Please use the product within one year after purchase.
