Tokyo Seimitsu Portable Surface Roughness Measuring Instrument Handysurf Plus 35 (2 microns) HANDYSURF PLUS35-2 1 unit

Catalog number: HANDYSURF PLUS35-2 Features: *Standard type allows measurement in any position, including inclined and vertical surfaces. *Display can be switched between 20 languages. *Supports high resolution and a wide measurement range. *Excellent operability with a 2.4-inch color LCD. *Fully-featured analysis functions allow waveforms and parameters to be checked on-site. *PLUS35 is a standard type, 40 is a retract type, and 45 is a horizontal trace type. Specifications: ● Measurement speed (mm/s): 0.5/0.6/0.75/1.0 ● X-axis (mm): 16 ● Pickup: Select E-DT-SM10A or E-DT-SM49B ● Power supply (V): AC100 ● X-direction (mm): 16 ● Evaluation length (mm): 0.2 to 16 ● Measurement range (μm) / Resolution (μm): -210 to +160 / 0.0007 ● Straightness precision (μm/mm): 0.5/16 ● Probe (μm): 2 ● Power supply: AC100 to 240 V ±10%, 50/60Hz single phase ● Power consumption: 10 W ● Probe: 2 μm Set contents / accessories: ● Standard piece ● Calibration stand ● HANDYSURF [+ above] dedicated carrying case ● V-shaped nosepiece ● Inspection report creation program SupportWare2● Additional options: small printers, various pickups, various nosepieces, offline analysis program (ACCTee), magnetic stands, etc.
