Catalog number: TM40X200 Features: ●A wide lineup has made it possible to standardize springs as mold parts. ●They are used widely by users not only in the mold industry but also as machine parts. Applications: ●Press molds ●Clutch and brake parts ●Precision machine parts ●Machine tool parts ●Seismic isolation parts Specifications: ●Outer diameter (mm): 40 ●Inner diameter (mm): 20.0 ●Free length (mm): 200 ●Spring constant (N/mm): 48.96 ●Maximum deflection (mm): 64.0 ●Maximum load (N): 3140 ●Rust prevention treatment: Electrochemical coating ●Usage temperature: -30 to 150°C Material/Finish: ●Silicon chrome steel for springs Caution: ●Do not use with deflections exceeding 32.0% of the free length.
