Junkosha Handy Touch Fitting Elbow 4 x 2.5 mm M5 BL-4X2.5-M5-BSN 1 pc

Catalog number: BL-4X2.5-M5-BSN Features: * Fittings exclusively for polyurethane tubes. * Can be used simply by inserting the tube and sleeve into the barb section. * Small and lightweight, so it does not take up piping space. * Nickel-plated, so there is no need to worry about rust. Uses: ● For connecting polyurethane tubes ● For general pneumatic piping ● For water pressure piping Specifications: ● Compatible tube outer diameter D (mm): 4 ● Connection size: M5 ● Hexagonal face size (mm): 10 ● Operating temperature range (℃): -20 to 60 (air), 0 to 50 (water) ● Fluid used: air, water ● Compatible tube inner diameter (mm): 2.5 ● Fluid used: air, water ● Fluid temperature: -20 to 60℃ (air), 0 to 50℃ (water) ● Maximum operating pressure: Complies with maximum operating pressure of tube ● Operating vacuum pressure: 0.014kPa or more (except US, when fluid used is air) ● Applicable tube (when fluid used is air): Polyurethane tube (UH, UF, UFL, UE, UC) ● Applicable tube (when fluid used is water): Polyurethane tube (UF, UFL) Material/Finish: ● Brass (nickel-plated) Set Contents/Accessories: ● Comes with a sleeve as an accessory. Note: If using polyurethane tubes other than the applicable tubes, please use tubes with an outer and inner diameter dimensional tolerance of 0.15 mm or less.
