It is lightweight and therefore suitable for transportation.
It has a safety structure that prevents the lid from being opened when pressurized. Material: Body/Stainless steel (SUS304), O-ring seal/NBR (nitrile rubber), relief valve/Perfluoro O-ring
Operating pressure: 0.49MPa or less
One-touch lever lock type
Outlet/pressure port connection: Top port (upper) Rc(PT)1/4
Capacity(L):10
Diameter x Height (mm): φ226 x 442
Weight(kg):2.7
TMB Series
*Custom-made processing is possible.
