3M Kanto High-K Insulator 2-EM (Salt Resistant) CVT14/22SQ Cable Kit HGT14/22G EM KANTO 1 S

Catalog number: HGT14/22G EM KANTO Features: ●After inserting the terminal body into the cable, simply crimping the terminal completes most of the work. ●There are very few tape wrapping points, making installation easy. ●Since silicone grease (lubricant) is built into the terminal body, you can work smoothly without getting your hands or parts dirty. ●Since the terminal body has a built-in grounding clamp, you can insert the cable and perform grounding at the same time. ●Since there is no protective plug on the terminal body, there is no need to remove the protective plug. ●The O-ring seal at the bottom of the terminal maintains airtight properties. ●Simply attach the terminal body and no additional waterproofing such as wrapping the outer layer with tape is required. ●The kit components are halogen-free and lead-free, so it can also be used with eco-cables (EM-CET cables). Applications: ●Terminals for 6600V CVT, CVT(EE), and EM-CET cables. Specifications: ● Compatible cable conductor size (mm2): 14, 22 ● Salt-resistant ● Compatible with Tokyo Electric Power Company's high-voltage service inlet wiring ● JCAA K 1301 standard product (No. 04001) Set contents/accessories: ● Terminal units x 3 sets, terminal covers x 3, 3M [TM above] self-fusing insulating tape (fit tape) x 1 roll, Scotch [R below] conductive copper foil tape 1245 x 3, positioning tape x 3, ACP semi-conductive tape x 1 roll, tin-plated soft copper wire x 1, fixing bolt and nut set x 6 sets, phase-coded tape (red, white, blue) x 1 sheet, work gauge x 1
