AION Kanefil FD 750mm Nominal accuracy 0.5μm FD-S05T 1 piece

Catalog number: FD-S05T Features: ●A depth-type cartridge filter in which the media fiber material is integrated three-dimensionally by the heat fusion method. ●It can remove eluates from the media to the maximum extent possible, and demonstrates extremely high performance in terms of cleanliness. ●It can be used not only for water-based systems, but also for chemical industries such as solvent-based paints and inks, as well as food applications. Applications: ●Water-based systems, paints, inks, chemical industries, pharmaceutical fields, and food. Specifications: ●Filtration accuracy (μm): 0.5 ●Outer diameter (mm): 65 ●Length (mm): 750 ●Compatible housings: 1CAT, 1VAT-5TS, 3HAT-5SR ●Inner diameter (mm): 30 ●Maximum operating temperature (℃): 60 ●Maximum operating temperature: 60℃ ●Recommended replacement differential pressure: 0.20MPa Material/Finish: ●Polypropylene (PP), polyethylene (PE) Caution: ●Make sure that the filter is securely set in the housing before using. ●When using the filter, please observe the pressure resistance, heat resistance, and replacement differential pressure.
