BAKER Back plunger type dial gauge type F01 BGF01 1 piece

Catalogue number: BGF01 Features: ● A dial gauge in which the spindle operates at right angles to the scale plate. ● The spindle is made of stainless steel, and the measuring element is equipped with a carbide ball anvil. ● Strong and smooth metal bezel, sturdy body. ● Comes with an inspection report containing actual measurement data. Applications: ● For use on machine tool tables, inspection jigs, and in narrow spaces. ● For precise measurement of parallelism and flatness. Specifications: ● Measurement range (mm): 0-2 ● Minimum display (mm): 0.01 ● Scale specifications: 0-50-0 ● Mounting shaft diameter (mm): 6.35 ● Measuring force (N): 1.5 or less ● Dial diameter (mm): 38
