CKD New Joint Stainless Steel Type (Straight, Single End) ZW-S4-6-P4 1 pc

Catalogue number: ZW-S4-6-P4 Features: ●Body and push ring are made of flame-retardant resin. ●All metal parts are made of stainless steel as standard. Applications: ●Tube connection Specifications: ●Compatible tube outer diameter (mm): 4 ●Connection port size: R1/8 ●Hexagonal face size (mm): 10 ●Operating temperature range (℃): -10 to 60 (no freezing) ●Compatible fitting size D (mm): 4 ●Total length (mm): 20.5 ●Operating fluid: Air ●Compatible tube outer diameter D (mm): 4 ●Operating pressure range: -100 kPa to 1.0 MPa ●Fluid temperature: 0 to 60℃ (no freezing) Materials/Finish: ●Body: Stainless steel (SUS303) + Polybutylene terephthalate (PBT) ●Seal rubber: Nitrile rubber
