CKD Pilot kick type 2-port solenoid valve (Multi-rex valve) APK11-8A-C4A-AC100V 1 unit

Catalog number: APK11-8A-C4A-AC100V Features: ●Multi-Rex valve series for controlling steam. Applications: ●For steam. Specifications: ●Effective cross-sectional area (mm2): 47 ●Connection port size: Rc1/4 ●Operation method: Piston-driven ●Power supply (V): AC100 ●Number of ports: 2 ●Fluid used: Steam ●Fluid temperature (℃): 5 to 180 ●Sonic conductance (C [dm3/(S・bar)]): 9.4 ●Operating pressure difference (MPa): 0 to 1 (steam) ●Fluid temperature: 5 to 180℃ ●Fluid used: Steam ●Open frame type lead wire (heat resistance class 180 (H)): 300mm ●Pilot kick type, NC (open when energized) type Materials/Finish: ●Body: Stainless steel ●Valve seal: PTFE ●O-ring: Fluorine rubber for steam
