Catalog number: W1000-6-W Features: ●Air filter and regulator are integrated into a compact unit. ●Removes drain and dust from the air and adjusts pressure. ●The element used has a unique chemical fiber structure that is rough on the surface and becomes finer toward the inside. ●Greatly eliminates clogging and significantly increases element life. Applications: ●Removes drain and dust from the air and adjusts pressure. Specifications: ●Filtration accuracy (μm): 5 ●Operating pressure (MPa): 1 ●Processing air flow rate (［［M3］］/min): 0.83 ●Set pressure (MPa): 0.05 to 0.85 ●Connection port size: Rc1/8 ●Total length (mm): 166.5 ●Total width (mm): 40 ●Operating fluid: Air ●Operating fluid: Air ●Fluid temperature: 5 to 60°C ●Drain discharge method: Manual ●With pressure gauge
