CKD Modular Type Selex FRL 2000 Series W2000-8-W 1 pc

Catalog number: W2000-8-W Features: ● Air filter and regulator integrated into a compact unit. ● Removes drain and dust from the air and adjusts pressure. ● The element used has a unique chemical fiber structure that is rough on the surface and becomes finer toward the inside. It greatly eliminates clogging and significantly increases the element life. Specifications: ● Filtration accuracy (μm): 5 ● Operating pressure (MPa): 1 ● Processed air flow rate (［［M3］］/min): 1.5 ● Set pressure (MPa): 0.05 to 0.85 ● Connection port size: Rc1/4 ● Overall length (mm): 235.5 ● Overall width (mm): 50 ● Used fluid: Air ● Used fluid: Air ● Fluid temperature: 5 to 60°C ● Drain discharge method: Manual ● With pressure gauge
