CKD Quick Exhaust Valve with One-Touch Fitting QEL Series Φ4 Atmospheric Release Type QEL-H44-S 1 pc

Catalogue number: QEL-H44-S Features: ●Effective in preventing condensation caused by adiabatic expansion. ●The valve body is made standard with ozone-resistant material to prevent deterioration. ●An environmentally friendly product whose materials are free of substances that have a negative impact on the global environment. Specifications: ●Connection diameter: 4 ●Compatible tube outer diameter D (mm): 4 ●Total length (mm): 35.2 ●Operating temperature range (℃): 5 to 60 ●Operating fluid: Air ●Effective cross-sectional area (［［MM2］］) (IN-OUT): 1.8 ●Effective cross-sectional area (［［MM2］］) (OUT-EXH): 1.8 ●Compact and space-saving
