CKD Direct acting 2-port solenoid valve (Multi-rex valve) AB41-02-5-03A-DC24V 1 unit

Catalog number: AB41-02-5-03A-DC24V Features: ●Multilex valve series that controls many types of fluids, including water, air, vacuum, and oil. Uses: ● For ON/OFF control of many types of fluids, including water, air, vacuum, and oil. Specifications: ● Effective cross-sectional area (mm2): 10.5 ● Connection diameter: Rc1/4 ● Operation method: Direct-acting poppet structure ● Power supply (V): DC24 ● Number of ports: 2 ● Fluids used: air, low vacuum, water, kerosene (up to 60°C), etc. ● Fluid temperature (°C): -10 to 60 ● Sonic conductance (C [dm3/(S·bar)]): 2.1 ● Maximum operating pressure difference (MPa) air: 0.5 ● Maximum operating pressure difference (MPa) water: 0.5 ● Operating pressure difference (MPa): 0 to 0.5 (air, water, kerosene, oil) ● Direct-acting, NC (close when energized) type ● Lead wire (mm): 300 Material/Finish: ● Body: Brass ● Sealing material: Nitrile rubber
