CKD Direct-acting 3-port solenoid valve (Multi-rex valve) AG31-01-2-AC100V 1 piece

Catalog number: AG31-01-2-AC100V Features: ●Multi-lex valve series that controls many types of fluids, including water, air, vacuum, and oil. Uses: ●For three-way control of many types of fluids, including water, air, gas, and oil. Specifications: ●Effective cross-sectional area (mm2): 2.65 ●Connection diameter: Rc1/8 ●Operation method: Direct-acting poppet structure ●Power supply (V): AC100 ●Number of ports: 3 ●Fluids used: air, low vacuum, water, kerosene (up to 60°C), etc. ●Fluid temperature (°C): -10 to 60 (no freezing) ●Maximum operating pressure difference (MPa) air: 0.4 ●Maximum operating pressure difference (MPa) water: 0.4 ●Operating pressure difference (MPa): 0 to 0.4 (air, water, kerosene), 0 to 0.25 (oil) ●Fluid temperature: -10 to 60°C (no freezing) ●Direct-acting, universal type ●Lead wire: 300mm Material/Finish: ●Body: Brass ●Sealing material: Nitrile rubber
