CKD Solenoid Valve 4K Series Pilot Type 5 Port Valve Select Valve Sonic Conductance 12 Connection Size Rc1/2 4KB410-15-DC24V 1 Unit

Catalog number: 4KB410-15-DC24V Features: ● Single solenoid type 5-port valve. ● Subplate piping. ● Improved wear resistance and sliding performance of the sliding parts, achieving a significant increase in lifespan and stable responsiveness. Applications: ● For driving cylinders of Φ125 to Φ160 Specifications: ● Connection diameter: Rc1/2 ● Power supply (V): DC24 ● Fluid used: Compressed air ● Fluid temperature (℃): 5 to 50 (no freezing) ● Sonic conductance (C [dm3/(S・bar)]): 12 ● Operating pressure: 0.15 to 0.7MPa ● Wire connection (mm): Grommet lead wire 300 Materials/Finish: ● Body: Aluminum die-cast, Spool packing: Nitrile rubber
