CKD FRL unit FRL combination Connection size Rc1/2 Processing air flow rate 3.0 C4000-15-WF 1 S

Catalog number: C4000-15-WF Features: ●Space-saving type that integrates a filter, regulator, and lubricator. ●The pressure gauge is embedded in the body, giving it a sleek design while ensuring safety. ●In the event of partial damage, it can be fixed by simply replacing the affected part. ●The element used has a unique chemical fiber structure that has a rough surface and becomes finer toward the inside. It greatly reduces clogging and significantly increases the element lifespan. Specifications: Filtration accuracy (μm): 5 Operating pressure (MPa): 1 Air flow rate (m3/min): 3.0 Connection diameter: Rc1/2 Oil storage capacity (cm3): 170 Overall length (mm): 226 Overall width (mm): 240 Set pressure (MPa): 0.05-0.85 Drain discharge method: Auto drain Fluid used: Air Fluid temperature (℃): 5-60 Drain discharge method: Auto drain Oil used: Turbine oil type 1 (equivalent to ISO VG#32) Pressure gauge, bracket included Note: For the C2500-8000-WF series, the minimum operating pressure of the auto drain is 0.1 MPa. Air is purged along with the initial drain until it rises to 0.1 MPa.
