Catalog number: OG55 Features: ● Self-locking press-in grip with nylon bushing insert is easy to install and will not come loose. ● Self-locking type, so it can be installed by simply inserting it firmly, so you can use the standard polished rod (tolerance h9) as is. Specifications: ● Outer diameter (mm): 33 ● Grip length (mm): 54 ● Shaft diameter (mm): 12 ● Shaft hole depth (mm): 40 ● Heat resistance temperature (℃): 110℃ Material/Finish: ● Grip: Phenolic resin ● Insert: Polyamide (PA)
