ENUMA EKC2050-X Double Pitch Sealed Chain EKC2050-X 96L DCKJ 1 piece

Catalog number: EKC2050-X 96L DCKJ Features: ●Sealed chain that complies with JIS A series and ANSI ISO A series chains. Applications: ●Power transmission and drive Specifications: ●Chain No.: 2050 ●Number of unit links: 96 ●Pitch (mm): 31.75 ●Roller outer diameter (mm): 10.16 ●Inner link inner width (mm): 10.16 ●Tensile strength (kN): 32.0 ●Maximum allowable load (kN): 6.3 ●Maximum allowable tension (kN): 6.3 ●Average tensile strength (kN): 32.0 ●Length (m): 3 ●Type: Split pin ●Roller shape: Small ●Rivet shape ●Double pitch shape ●Type: Split pin Material/Finish: ●Steel
