icotek [Sold out item] Round cable entry plate φ25 for 4 cables KEL-DPZ25-4-43737 1 piece

Catalogue number: KEL-DPZ25-4-43737 Features: ● Cut cables or fluid hoses can be pushed in directly by breaking through the membrane. ● Up to four 3.2 to 5.2 mm cables can be assembled. ● Quick and easy assembly without tools. ● High cable density. Applications: ● For consolidating up to four cables with different outer diameters in one round hole. Specifications: Color: Gray; Suitable wire diameter (mm): 3.2-5.2mm; Mounting screws: Included lock nut; Wrench size (mm): M25; Suitable plate thickness: 1-7mm; Grommet: For 4 pieces; Height (mm): 39; Width (mm): 39; Depth (mm): 8; Outer diameter (mm): 32; Clamping range (mm): 3.2-5.2; Maximum (pieces): 4; EN45545-2; ECOLAB approved; Halogen free; Silicone free; Strain relief EN62444; UL94-V0 Material/Finish: Frame: Polyamide, Seal plate: Elastomer
