Catalog number: M1.5B46 Features: ●Tooth precision: Standard grade (old JIS class 4, new JIS class N8) spur gear. Applications: ●For all kinds of machines, such as printing machines, automatic packaging machines, and electrical parts manufacturing lines. Specifications: ●Module: 1.5 ●Number of teeth: 46 ●Reference circle diameter d (mm): φ69.0 ●Tooth width b (mm): 15 ●Hole diameter (mm): φ12 ●Total length l (mm): 25 ●Shape: S1 ●Tooth tip circle diameter (mm): φ72 ●Reference circle diameter (mm): φ69 ●Boss diameter (mm): φ45 ●Tooth width (mm): 15 ●Total length (mm): 25 ●Gear: Standard teeth ●Pressure angle: 20° Material/Finish: ●Carbon steel for machine construction ●Surface treatment: Black dyeing
