KHK Worm Wheel AG0.8-40R1 AG0.8-40R1 1 piece

Catalog number: AG0.8-40R1 Features: ● Worm wheel made of aluminum bronze with excellent wear resistance. ● Wide variety of products available. Applications: ● Gears for power transmission. Specifications: ● Module: 0.8 ● Number of teeth: 40 ● Hole diameter (mm): φ6 ● Tooth shape: Straight teeth ● Shape: HA ● Total length: 16 ● Boss diameter: 20 ● Tooth tip circle diameter: 33.6 ● Reference circle diameter: 32 ● Tooth width: 8 ● Boss length (right): 8 ● Gear precision: KHK W 002: Class 2 ● Surface treatment: None ● Pressure angle: 20° ● Tooth surface finish: None ● Gear cutting reference surface: Hole (H7) ● Heat treatment: None ● Additional processing possible: Yes Material/Finish: ● CAC702 Note: ● Sold individually, not as a set.
