MAPAL MEGA-Drill-Reamer (SCD200C) External oil supply X5D SCD200C-1000-2-4-140HA05-HP835 1 piece

Catalog number: SCD200C-1000-2-4-140HA05-HP835 Features: ●One-shot machining of H7 precision holes, "centering + drilling + reamer" 3 processes can be consolidated into 1 process. ●Excellent centripetal movement due to the distinctive chisel design and combination land. ●Ideal for machining positioning holes and knock pin holes. Applications: ●Workpiece: Carbon steel, alloy steel, cast iron, light alloy. Specifications: ●Blade diameter (mm): 10 ●Groove length (mm): 61 ●Total length (mm): 103 ●Shank diameter (mm): 10 ●Effective machining depth: 5D (blade diameter x 5 times) ●Surface treatment: HP835 coating ●H7 tolerance specifications Material/Finish: ●Micro grain carbide
