NOGA Monoblock Box Set 16000N KM06-110 1 S

Catalogue number: KM06-110 Features: ●The clamp height can be easily adjusted without using a height adjustment block or adjustment plate, and a constant clamping force is maintained. ●The monoblock clamp is fixed to the table using a screw. ●It can be easily fixed to a table with a T-slot or a table with a screw hole using a tightening screw. Specifications: ●Clamping force (N): 16000 ●Clamping height (mm): 0-154 ●Included T-nuts (mm): 2 each for 14, 16, and 18 slots ●Arm length (mm): 33 ●Clamping force 16000N ●Monoblock short arm Set contents/accessories: ●2 monoblocks, 2 riser blocks, 1 clamping key, 1 extra long arm, 4 M10 screws, 6 M10 spring-loaded T-nuts
