NOGA V-Block Magnet Set (VB1002 + NF60103) Arm Type VB1300 1 S

Catalog number: VB1300 Features: ●By combining the V-block magnet with NOGA's unique holder, processing and inspection can be done with one tool (V-block magnet with holder). Applications: ●For processing and inspection of products. Specifications: ●Width (mm): 70 ●Depth (mm): 100 ●Height (mm): 95 ●Suction force (N): 300 (top surface) 600 (bottom surface) ●Usable diameter (φ): 8-52 ●Thread size (inner diameter): M5 ●Clamp range (mm): φ8-52 ●Suction force (N) (top surface): 300 ●Suction force (N) (bottom surface): 600 ●Measuring instrument mounting: Φ6mm, 8mm, 3/8 inch hole, dovetail groove ●All usable surfaces are precision polished Set contents/accessories: ●VB1002+NF60103 Note: ●Test indicator and dial gauge are sold separately.
