日進工具（株）
NS Super Speed Ball End Mill SSBL200 R0.075X0.75 SSBL200 R0.075X0.75 1 piece
NS Super Speed Ball End Mill SSBL200 R0.075X0.75 SSBL200 R0.075X0.75 1 piece
Regular price
¥31,522
Regular price
Sale price
¥31,522
Unit price
/
per
Shipping calculated at checkout.
Couldn't load pickup availability
Catalog number: SSBL200 R0.075X0.75 Features: ●The long life of CBN and the long neck shape allow for new machining areas. ●Can handle deep engraving. Applications: ●Workpiece: Pre-hardened steel, high-hardness steel. Specifications: ●Ball radius (mm): 0.075 ●Neck length (mm): 0.75 ●Blade length (mm): 0.12 ●Total length (mm): 50 ●Shank diameter (mm): 4 ●Number of teeth (pieces): 2 ●Number of teeth: 2 ●Effective length (mm): 0.75 ●Bottom blade shape: Ball Material/Finish: ●CBN
