OMRON Mini Power Relay MY2N DC24 1 piece

Catalog number: MY2N DC24 Features: ● General-purpose relay. ● Best-selling general-purpose relay. ● Can be selected according to the application, such as with operation indicator, with latching lever, with built-in diode, with built-in CR circuit, etc. ● With light insertion force and strong pull-out strength, it can be combined with Push-In Plus terminal socket (PYF-□-PU), which reduces wiring labor, to reduce wiring labor by 62% compared to conventional screw terminal sockets. Applications: ● For control panels. ● For configuring various control systems such as control circuits for automatic machines used in various production sites, building lighting, air conditioning, and water treatment. Specifications: ● Contact configuration: 2c ● Rated voltage (V): DC24 ● Rated current (A): 5 ● Contact rating: resistive load AC220V 5A, DC24V 5A ● Eliminates the use of lead, contributing to environmental conservation ● Additional VDE standard (Germany) obtained ● Equipped with an operation indicator light that shows the operating status ● Improved identification of AC/DC coil voltage specifications through color-coding of the coil tape and operation indicator light (LED) ● Available in a variety of contact materials and contact mechanisms to suit contact reliability and corrosion resistance. Note: ● Optional items (connection sockets, holding brackets, etc.) are sold separately.
